RPi Camera V2

SKU: 11633
Part Number: RPi Camera V2

$27.99
$27.392+
$27.093+
$26.974+

Related Products:

Description

Details

Official Raspberry Pi Camera Board V2

Features

  • Official Raspberry Pi Camera Board, supports Raspberry Pi, CM3/3+/4, Jetson Nano, Jetson Xavier NX
  • IMX219 8-megapixel sensor
  • Camera specifications
    • CCD size : 1/4inch
    • Aperture (F) : 2.0
    • Focal Length : 3.04mm
    • Angle of View (diagonal) : 62.2 degree
  • 3280 × 2464 still picture resolution
  • Support 1080p30, 720p60 and 640x480p90 video record
  • Dimension: 25mm × 24mm × 9mm

Note: to use the camera with Raspberry Pi Zero / Zero W / Zero WH, you need to buy a specific cable: Raspberry Pi Zero v1.3 Camera Cable

Development Resources

Wiki : www.waveshare.com/wiki/RPi_Camera_V2

Selection Guide

Partnumber IR filter Aperture Focal Length (mm) Adjustable Focus Distance Angle of View (diagonal) Dimensions (mm)
RPi Camera (B) integrated 2 6 60.6° 32×32
RPi Camera (E) N/A 2.8 3.21 - 69.8° 25×24
RPi Camera (F) N/A 2 3.6 50° 25×24
RPi Camera (G) integrated 2.35 3.15 160° 25×24
RPi Camera (H) N/A 2.35 3.15 160° 25×24
RPi Camera (I) integrated 2 1.85 185° 32×32
RPi Camera (M) integrated 2 0.87 200° 25×24
RPi IR-CUT Camera N/A 2 3.6 50° 31×32
RPi IR-CUT Camera (B) N/A 1.4 8 40° 31×32
RPi Zero V1.3 Camera integrated 2.8 3.21 - 69.8° 60×11.5
RPi FPC Camera integrated 2.8 3.21 - 69.8° 300×16
RPi FPC Camera (B) N/A 2.4 3.89 - 72.9° 35×16×5
  • Unless otherwise specified, cameras on the table are compatible with Raspberry Pi, CM3/3+/4, please refer to the detail product page for more information.
  • Normal IR cameras will take curious reddish pictures by daylight for lacking of IR filter in the CCD, and that is the reason why they can capture image in the night by using IR fill light.
    If you're looking for cameras that can capture image in correct color in both day and night, please choose RPi IR-CUT Camera and RPi IR-CUT Camera (B).

Weight: 0.028 kg

Quick Overview

The included FFC is 15cm, if you need a longer cable, please consider: RPi Camera Cable 60cm

  1. RPi Camera V2 x1
  2. 15-pin FFC (opposite sides contact) x1
