Infrared Reflective Sensor

SKU: 9523
Part Number: Infrared Reflective Sensor
Brand: Waveshare

$3.89
$3.692+
$3.493+
$3.294+

Description

Details

Infrared Reflective Sensor

Overview

  • Reflective infrared Transceiver
  • Features wide range voltage comparator LM393
  • Adjustable sensitivity
  • Signal output indicator

Specifications

  • Power: 3.0V ~ 5.3V
  • Dimension: 25mm * 15.9mm
  • Mounting holes size: 2.0mm

Applications

  • Robot path tracking
  • Obstacle-avoiding car
  • Pipeline counter

How to Use

In the case of working with a MCU:

  • VCC ↔ 3.0V ~ 5.3V
  • GND ↔ power supply ground
  • AOUT ↔ MCU.IO (analog output)
  • DOUT ↔ MCU.IO (digital output)

Photos


Downloads

Development resources: demo codes, schematic, datasheets, etc.
Wiki: www.waveshare.com/wiki/Infrared_Reflective_Sensor

Weight: 0.005 kg

Quick Overview

  1. Infrared Reflective Sensor x1
  2. 4-pin custom connector jumper wire x1
