Waveshare Jetson TX2 NX Development Kit, Deep Learning and Edge Computing
Jetson TX2 NX Development Kit

Delivers The Next Step In AI Performance For Embedded & Edge Computing

Based On Jetson TX2 NX Module

NVIDIA Jetson TX2 NX delivers the next step in AI performance for entry-level embedded and edge products. It provides 2.5X the performance of Jetson Nano, integrating NVIDIA Pascal architecture with 256 NVIDIA CUDA cores and the AI performance reaches up to 1.33 TFLOPs.

This kit includes a TX2 NX Module with onboard 16GB eMMC, does not support Micro SD card.

Comes with extra Free Accessories
Dedicated Cooling Fan for Powerful
Heat Dissipation

Adopts NVIDIA classic cooling fan appearance, aluminum alloy enclosure, speed up to 5500RPM. Powerful heat dissipation, no worry about the drop in AI performance due to heat dissipation problems.

High-quality carrier board for
Better Performance

High-quality carrier board to match the strong performance of the TX2 NX Module. Waveshare is widely praised for the board durability and manufacturing quality. We optimize each part of the board with good workmanship and materials.

Waveshare Jetson Series
Product Comparison
ProductNano Developer KitTX2 NX Developer KitXavier NX Developer Kit
Version NVIDIA Official B01 Kit Waveshare Waveshare NVIDIA Official Kit Waveshare
AI Performance 0.5 TFLOPS (FP16) 1.33 TFLOPS 21 TOPS
GPU NVIDIA Maxwell, 128 NVIDIA CUDA Core NVIDIA Pascal architecture with 256 NVIDIA CUDA cores 384-core NVIDIA Volta GPU with 48 Tensor Cores
CPU 4-Core ARM Cortex-A57 MPCore CPU Dual-core NVIDIA Denver 2 64-bit CPU and Quad-core Arm Cortex-A57 MPCore processor complex 6-core NVIDIA Carmel ARM v8.2 64-bit CPU
6MB L2 + 4MB L3
Memory 4 GB 64-bit LPDDR4
1600Mhz 25.6GB/s
4 GB 128 bit LPDDR4
51.2 GB/s
8 / 16 GB 128-bit LPDDR4x
59.7GB/s
Storage Micro SD card
(should be purchase separately)
16 GB
eMMC 5.1
16 GB eMMC 5.1 Micro SD card
(should be purchase separately)
16 GB
eMMC 5.1
Free Storage None 32 GB U disk 128 GB SSD None 128 GB SSD
Power 5W | 10W 7.5W | 15W 10W | 15W | 20W
PCIe M.2 E KEY (PCIe Gen 2 x1) M.2 E KEY (PCIe Gen 4 x1)
M.2 M KEY (PCIe Gen 4 x4)
CSI 2 MIPI CSI-2 DPHY Channel
Video Encode 4Kp30
4x 1080p30
9x 720p30 (H.264/H.265)
1x 4K60
3x 4K30
4x 1080p60
8x 1080p30 (H.265)
1x 4K60
3x 4K30
7x 1080p60
14x 1080p30 (H.264)
2x 4K60
4x 4K30
10x 1080p60
22x 1080p30 (H.265)
2x 4K60
4x 4K30
10x 1080p60
20x 1080p30 (H.264)
Video Decode 4Kp60
2x 4Kp30
8x 1080p30
18x 720p30 (H.264 / H.265)
2x 4K60
4x 4p30
7x 1080p60
14x 1080p30
(H.264 / H.265)
2x 8K30
6x 4K60
12x 4K30
22x 1080p60
44x 1080p30 (H.265)
2x 4K60
6x 4K30
10x 1080p60
22x 1080p30 (H.264)
Display HDMI 2.0 / DP1.2 HDMI 2.0 / DP 1.4
DL Accelerator - - 2x NVDLA Engines
Vision Accelerator - - 2x PVA
Networking 10/100/1000 BASE-T Ethernet
Dimensions 100 x 80 x 29 mm 103 x 90.5 x 34 mm

Compact, Powerful Performance At The Edge

The NVIDIA Jetson TX2 series modules deliver exceptional speed and power efficiency for embedded AI computing devices, delivering 1.33 TFLOPS of AI performance. Equipped with NVIDIA Pascal GPUs, up to 4 GB memory, 51.2 GB/s memory bandwidth, and a variety of standard hardware interfaces.


With Cloud-Native Support

Jetson TX2 NX modules cloud-native support lets developers build and deploy high-quality, software-defined features on embedded and edge devices. Pre-trained AI models from NVIDIA NGC and the TAO Toolkit give you a faster path to trained and optimized AI networks, while containerized deployment to Jetson devices allows flexible and seamless updates.

Ideal For Critical Embedded Applications

Jetson TX2 NX is perfect for high-performance AI systems like commercial robots, medical instruments, smart cameras, high-resolution sensors, automated optical inspection, smart factories, and other IoT embedded systems.

Image Recognition

Object Recognition

Semantic Segmentation

Pose Estimation

Monocular Depth

Position Tracking

AI Computing Neural Networks SDK

Jetson Development Pack (JetPack) is an on-demand all-in-one package that bundles and installs all development software tools for the NVIDIA Jetson embedded platform.


Jetson TX2 NX Module Specification
AI Performance 1.33 TFLOPS
GPU NVIDIA Pascal Architecture with 256 CUDA cores
CPU Dual-core NVIDIA Denver 2 64-bit CPU and Quad-core Arm Cortex-A57 MPCore processor complex
Memory 4 GB 128 bit LPDDR4 51.2 GB/s
Storage 16 GB eMMC 5.1
Power 7.5 W | 15 W
PCIe 1x1 + 1x2
PCIe Gen2, total 30 GT/s
CSI Up to 5 cameras (up to 12 via virtual channels)
12-Ch MIPI CSI-2 (3x4 or 5x2)
D-PHY 1.2 (up to 30 Gbps)
Video Encode 1x 4K60 | 3x 4K30 | 4x 1080p60 | 8x 1080p30 (H.265)
1x 4K60 | 3x 4K30 | 7x 1080p60 | 14x 1080p30 (H.264)
Video Decode 2x 4K60 | 4x 4p30 | 7x 1080p60 | 14x 1080p30
(H.265 and H.264)
Display 2 Multimode DP 1.2/eDP 1.4/HDMI 2.0
1 x 2 DSI (1.5Gbps/lane)
Networking 10/100/1000 BASE-T Ethernet
Dimensions 69.6 mm x 45 mm
260-pin SO-DIMM connector
Outline dimensions

Quick Overview

  1. Waveshare TX2 NX development kit:
    Jetson TX2 NX Module
    JETSON-IO-BASE-B
    Cooling Fan
  2. 128GB NVMe SSD
  3. Wireless network card
  4. OPTIONS Power adapter
